EV Pillars & Panels

Our EV Feeder Pillars & Panels range is expertly designed to provide reliable power distribution for EV Charging Systems and other critical infrastructure.

Built to comply with all relevant industry standards they ensure safe and long-lasting performance. All of our Feeder Pillars & Panels are manufactured in accordance with ISO 9001:2015, BS EN 61439 standards and are UKCA marked for compliance.

Get A Quote

View Specifications

EV Brochure

tofco-ev-pillars-and-panels-3-compressed

tofco-ev-pillars-and-panels-4-compressed

tofco-ev-pillars-and-panels-5-compressed

Jump to:

Overview

Features & Benefits

Technical Specifications

Bespoke Solutions

Product Overview

Robust and durable design to withstand various environmental conditions.
Suitable for a wide range of applications, including Street Lighting, EV Charging and Industrial Power Distribution.
Manufactured in the UK using high-quality materials and processes.
Designed for long-term reliability and safety, meeting industry compliance standards.

Features & Benefits

Customisable Options:

Available in ratings up to 3200A, multiple configurations available to meet specific project requirements.

Durable Construction:

Engineered with high-quality materials such as steel or GRP for enhanced strength and corrosion resistance.

Ease of Installation:

Pre-wired configurations simplify and speed up the installation process.

Low Maintenance:

Designed for minimal upkeep, reducing operational costs over time.

Safety Compliance:

All products are manufactured to BS EN 61439 and UKCA marked for adherence to safety and industry standards.

Contact Sales

Technical Specifications

EV Pillars & Panels Enquiry Form

Download the form

View Details

Get A Quote

Download
100A

The 100A EV Pillar and Panel may be supplied in 3mm HDG steel or GRP. Single or Three phase variants are available.

View Details

Get A Quote
100A – TEV100

Description: 100A 3 Phase

DNO & Private Supply Option: Yes

Dimensions:
- Height: 1200mm
- Width: 1200mm
- Depth: 472mm
- Weight: 177kg
Standard Charging
- 7.4kW (32A SPN): Yes
  - Max Charge Points: 9*
- 22kW (32A TPN): Yes
  - Max Charge Points: 3*
Fast Charging
- 43kW (63A TPN): Yes
  - Max Charge Points: 2
- 50kW (80A TPN): Yes
  - Max Charge Points: 1
Ultra Fast Charging
- 120kW (250A TPN): No
* More charge points can be supplied with load balancing enabled EV chargers
200A

The 200A EV Pillar and Panel may be supplied in 3mm HDG steel or GRP.

View Details

Get A Quote
200A – TEV200

Description: 200A 3 Phase

DNO & Private Supply Option: Yes

Dimensions:
- Height: 1490mm
- Width: 1520mm
- Depth: 472mm
- Weight: 255kg
Standard Charging
- 7.4kW (32A SPN): Yes
  - Max Charge Points: 18*
- 22kW (32A TPN): Yes
  - Max Charge Points: 6*
Fast Charging
- 43kW (63A TPN): Yes
  - Max Charge Points: 4
- 50kW (80A TPN): Yes
  - Max Charge Points: 3
Ultra Fast Charging
- 120kW (250A TPN): No
* More charge points can be supplied with load balancing enabled EV chargers
400A

The 400A EV Pillar and Panel may be supplied in 3mm HDG steel or GRP.

View Details

Get A Quote
400A – TEV400

Description: 400A 3 Phase

DNO & Private Supply Option: Yes

Dimensions:
- Height: 1800mm
- Width: 1470mm
- Depth: 745mm
- Weight: –
Standard Charging
- 7.4kW (32A SPN): Yes
  - Max Charge Points: 36*
- 22kW (32A TPN): Yes
  - Max Charge Points: 12*
Fast Charging
- 6no (63A TPN): Yes
  - Max Charge Points: 4
- 5no (80A TPN): Yes
  - Max Charge Points: 3
Ultra Fast Charging
- 1no (250A TPN): No
* More charge points can be supplied with load balancing enabled EV chargers
630A-1600A

Available in ratings from 630A up to 1600A with multiple and bespoke combinations of outgoing circuit breakers.

View Details

Get A Quote
630A-1600A

Description: EV Hub Pillar Above 630A

DNO & Private Supply Option: NO – Private Only

Dimensions (starting from):
- Height: 1800mm
- Width: 1470mm
- Depth: 745mm
- Weight: –
Outgoing Devices

We can supply devices in any size or configuration required, as standard our EV Hub pillars as setup to recieve up to 6no 630A 4 Pole outgoing MCCBs but any size or configuration as required can be designed

Get in touch to find out more

Case Studies

Related Products

Turn-Key Solutions

TOFCO’s Turn-Key Solutions offer fully integrated solutions to meet the evolving needs of the EV Power Distribution infrastructure.

Learn More

EV Isolators

Our EV Isolator Units are a critical component in EV Charging infrastructure providing essential protection and disconnection features for high-voltage installations.

Learn More
